Place of Origin:
CHINA
Brand Name:
SINTEK
Model Number:
HQ600
The machine is a high efficiency, high precision six- axe bus bar processing machine thatcontrolled by computer/ This machine is a special equipment for high efficiency and highprecision six- axe bus bar full CNC processing system which is mainlyaimedat the copper andaluminum bus bar.It includes: punching, cutting,chamfering, embossing, etc.Nomanual intervention is needed inthe process of bus bar processing,which has theadvantages offastprocessing speedand high precision,It is widelyused in high and lowvoltagecompleteset, switch gear and box-type substation etc.
|
Unit |
Data |
|||
|
Nominalpressure |
Punching unit |
kN |
600 |
|
|
Cuttingunit |
kN |
600 |
||
|
Embossing unit |
kN |
600 |
||
|
No.of molds |
Punching unit |
SET |
7 |
8 |
|
Cuttingunit |
SET |
1 |
1 |
|
|
Embossing unit |
SET |
1 |
0 |
|
|
Mainstrikecylinderstrike frequency. |
HPM |
120-150times/min (20mmtrip) |
||
|
No.Ofcontrol axe |
axe |
6 |
||
|
Holesdistance controlaccuracy. |
mm/m |
± 020 |
||
|
Maxpunchingdiameter |
mm |
Ø4.3- 35 (round) |
||
|
Maximumcompressivearea. |
mm2 |
160×50 |
||
|
X- axis max positioningspeed. |
m/min |
75 |
||
|
MaxeffectivestrokeofXaxis. |
mm |
2000 |
||
|
X-axis accuracy error |
mm |
0.20/500( not accumulate) |
||
|
Y- axis max positioning speed. |
m/min |
40 |
||
|
MaxeffectivestrokeofYaxis. |
mm |
960 |
||
|
Y-axis accuracy error |
mm |
0.20/500( not accumulate) |
||
|
Z- axis maxtravel trip |
mm |
310 |
||
|
Ramstroke |
mm |
45 |
||
|
Max sizeforbusbar |
mm |
6000(nolimited),200,15(length,width,thickness) |
||
|
Min sizeforbusbar |
mm |
20 × 3( length ×width × thickness) |
||
|
Area of hoststation. : |
mm |
10500× 2900× 1700( length ×width) |
||
|
Total power |
kW |
22 |
||
